Mineral powder v mixer blender is used for mix two or more than two kinds of dry granules or powder materials in the pharmaceutical, food, chemical, or other related industries.
When mix sticky or bad fluidity powder, intensifier agitator is highly recommended, the mixing effect will be much better. Particularly it can also mix raw material that needs to add a small amount of additive.
- Price Term: FOB/CIF/EXW
- Package: Wooden case or according to customer request
- Delivery Time: 25-35 working days
- Transports: LCL/FCL
- Shipment Port: Shanghai Port
- Origin Of Place: Wuxi City
- Warranty: 12 Months
- Introduction
- Specifications
| Model | YDV-180 | YDV-300 | YDV-V500 | YDV-1000 | YDV-1500 | YDV-2000 |
| Volume(L) | 180 | 300 | 500 | 1000 | 1500 | 2000 |
| Max Production Capacity(kg/patch) | 40 | 70 | 120 | 250 | 360 | 450 |
| Mixing time(Min) | 4-8 | 4-8 | 6-10 | 6-10 | 12-18 | 12-18 |
| Barrel speed(r/min) | 12 | 12 | 12 | 12 | 12 | 12 |
| Motor power(kW) | 1.1 | 1.5 | 2.2 | 4 | 5.5 | 7.5 |
| Material Thickness(mm) | 3mm | 4mm | 5mm | 6mm | ||
| Distance between the shaft and inner wall | 1.5mm | 3mm | ||||
| Model of auxiliary vacuum pump(option) | Manual feeding | Manual feeding | WL50 | WL50 | WL50 | WL50 |
| Cross rotation height (mm) | 1870 | 1870 | 2450 | 2940 | 2940 | 3670 |
| Overall dimension(mm) | 2110*600*1675 | 2000×750×1650 | 2380×1100×1950 | 2900×1300×2500 | 3390×1350×2900 | 3700×1600×3100 |
| Weight | 290 | 380 | 550 | 700 | 900 | 1500 |
Hot-selling Equipments For Your Powder Processing Task
Mineral Powder V Mixing Blender For You Powder Handling Task:
Specialty Yinda mineral powder v mixer:
●Simple structure, polished surface, easy to maintain, and keep tidy, this characteristic can avoid drug cross-contamination, especially for pharmaceutical companies.
●Heating or cooling jacket is optional, if temperature control is required, spray nozzles for the liquid introduction.
●It can work with a vacuum conveyor to achieve automatic feeding and prevent dust.
●Safety bar can be optional,. mixer can work when the safety bar is in a horizontal position. This function will protect the operator from possible injury from the rotating V mixing barrel.
●Add nozzles to mix the powder with liquid can be optional. No dead angle, no accumulation of materials, high speed, and short mixing time, high uniform mixing.
●Adjustable rotating speed, the digital display is optional, auto-positioning stop function is optional when the machine stops, the discharge parts are right towards the ground automatically, no need to use point-stop (jog) manually.
Detailed Images of Mineral Powder V Mixing Blender:
Inner Agitator:
●304 SUS steel material
●uniform mixing and shorter mixing times via positive agitation technology.
Operation Panel:
●button control
●Limit switch
●automatically mixing time setting
Manual Butterfly Valve for discharge:
●prolong service life
●improve mixed uniformity
Eu Brand components guarantee quality performance and minimize broken-down time.
