Cost-effective V Type Blender Factory
As a professional V Type Blender manufacturer and factory in China, we manufacture and supply all types of V Type Blender are available in many different sizes to meet various capacity requirements. In addition, we can also customise our cone mixer to meet specific machining requirements, including special designs that can be sterilised, heated, dried, etc.
We have an extensive stock of V Type Blender and replacement parts, can be shipped quickly to anywhere in the world and a wide range of delivery options are available.
Do get in touch with us and let us know how we can help when it comes to V Type Blender, being always here to help you choose an efficient machine.
Yinda: Your Reliable V Type Blender Supplier In China
1)If you project on powder processing needs to import V Type Blender then Yinda will be your best choice to manufacture your V Type Blender orders.
2)Yinda is one of the leading V Type Blender suppliers and all of our V Type Blender can meet ISO/CE/GMP standards, and we will provide a competitive price based on your project.
3)Yinda will give you the best V Type Blender solution based on your project’s requirements with our professional technical team, and lean more about powder handling process that we enjoy sharing with customers.
4) Drop us an email and send your detailed requirement now!
- Specifications
- Main Features
- Package And Shipment
- Industrial Applications
- Ultimate service
|
Model
|
YDV-100 | YDV-200 | YDV-300 | YDV-500 | YDV-1000 | YDV-1500 | YDV-2000 | YDV-3000 | YDV-4000 |
|
Volume (L) |
100 | 200 | 300 | 500 | 1000 | 1500 | 2000 | 3000 |
4000 |
|
Load Coefficient |
0.3-0.4 | ||||||||
| Motor power(kw) | 1.1 | 1.1
|
1.5
|
2.2
|
4
|
5.5
|
7.5
|
7.5 |
11 |
|
Overall size(mm) |
1850×660×1500 | 2110*600*1675 | 2280*630*1780 | 2655*1040*2250 | 3070*1240*2490 | 3900*1440*3100 | 3900*1440*3100 | 4690*2200*4000 | 4950*2200*4230 |
|
Weight (kg) |
230 | 290 | 400 | 550 | 860 | 1040 | 2040 | 2200 |
2800 |
The loading of the materials in the blender is through the two ends or by the apex port. You add the materials up to 50%-60% of the total volume of the blender. The time of blending is just 5 to 15 minutes. The materials get discharge from the apex of the blender.
- The V-type blender performs the operations in batches. It helps in blending homogenously with quality control.
- No need to apply any force or stress to blend the powder. All the materials blend gently and deliver the best outcome.
- In-vessel, there is no dead space, and you can discharge the whole product from it after the completion of blending.
- The V-shape blender is easy to clean and maintain. Because all the internal surfaces are polished and there are no corners.
- It requires installation at a minimum level as it is ready to start working
- The fitting of the inlets is along with the air-tight covers that assure no contamination in the blending procedure.
- The complete design of the V-type blender is compact and complete
- You can also add liquids to the system by the gravity of the tank or pressure pump.
- It always delivers high profit as its production capacity is high as well.
- The consumption of the power by the blender is low and requires less maintenance.
- The blending process works gently without causing any deformation of the particles. It can also break the lumps with the help of an intensifier and discharge the output in less time.
- The loading and discharge time prevents the downtime of the blender.
- In the absence of fluidity in the materials, you can use an agitator as an option.
- The spraying device is also available for injecting the liquid on a small scale.
- The V-shape blender is stable enough without making any noise.
- Option of protecting the device from overloading the materials is also present
Hot-selling Equipments For Your Powder Processing
V Type Blender – The Complete FAQ Guide
Can’t decide choosing if you need a V type blender or a double cone blender for your powder processing? Don’t worry, in this guide, we’ll give you everything you need to know about V type blenders.
Not only will you learn what V type blenders are, you will also get high-quality information that you can use in finding the best V type blenders in the market!
What is a V Type Blender?
From its term alone, you would already get the idea of what this particular type of machine is.
Figure 1 – A sample image of what a V type blender looks like
For the benefit of everyone, though, V type blenders are powder handling and powder processing machines that are shaped as a letter V and are responsible for the homogenous mixture of different types and kinds of powders.
They’re much like double cone blenders, ribbon blenders, and others of the same kind. They’re only different because the chamber or the vessel is V-shaped.
What is a Twin Shell Blender?
Figure 2 – A sample image of what a twin shell blender looks like
Twin shell blenders and V type blenders are literally the same thing! From the term “twin shell,” they’re two (2) shells that are 100% symmetrical and alike that are conjoined at an angle where they’ll function as one.
Don’t be confused when you encounter the term twin shell blenders in the market – they’re V type blenders, too!
How Do You Clean V Blenders?
The cleaning procedure or process of V blenders is typically easy. In fact, the cleaning process of V type blenders is simply and easy!
Figure 3 – Image of a V type blender inner part
Here’s how you can clean V blenders!
- Fill the V type blender with hot water about halfway the maximum capacity.
- Add a disinfectant and a cleaning agent to help and aid the process.
- Turn the blender on, let it tumble for about 5 to 10 minutes.
- Drain the water with the cleaning solution.
- Rinse it out with hot water by turning it on and activating it again.
That’s it! That’s how you clean V type blenders! Do note, though, that in the process, you can use other types of agents and detergents to remove contaminants or any other type of unwanted chemicals that might have stuck and attached onto the blender.
Double Cone Blenders vs. V Type Blenders vs. 3D Blenders
They’re all blenders, don’t they just do the same thing? Are there differences in terms of process and results?
Figure 4 – A double cone blender and a V type blender
Double cone blenders, 3D blenders, and V type blenders are not the same, though a lot of people believe that they do.
Figure 5 – A 3D or 3-dimensional blender
To help you distinguish and arrive at the conclusion of how they’re different, here’s a table that would quickly address those.
| 3D Blenders | Double Cone Blenders | V Type Blenders |
| Ideal for mixing up to two (2) ingredients only. | Can mix two (2) to five (5) ingredients. | Can mix up to 10 different ingredients. |
| Ideal for mixing low-viscosity liquids only. | Wet mixing and blending is applicable. | Wet mixing and blending is applicable. |
| Mixing occurs by powders sliding on the walls of the vessel. | The mixing happens through the help of troughs within the vessel. | Mixing occurs thanks to the narrow shells of the blender. |
| Can be difficult to clean because of the corners. | Easy to clean because of wide gapes and opening. | Easy to clean because of its natural shape. |
So, the next time that you’re faced with the problem of the type of blender you want to use, you can try going back to this guide to check and see how they’re different from one another.
V Type Blender Working Principle
V type blenders work in accordance to the shape of the shells or the chambers. For you to understand them even further, the idea of how V type blenders work is that the particles and materials are mixed inside the chambers, allowing the continuous blending and mixing.
Through the process called diffusion blending, the materials within the V type blender are consecutively and continuously rotated until the mixtures wanted and needed are achieved.
The speed in which the blender moves would incrementally heighten and increase as the process goes deeper into the procedure.
What Are the Applications of V Type Blenders?
V type blenders aren’t just restricted to be used in industries and sectors that utilize dry powders.
Figure 6 – You can use V type blenders for mixing and blending dry powders
In fact, you can use V type blenders in a lot of different applications. You can use them if you are involved in any of the following business industries:
- Pharmaceutical Industry
- Chemical Industry
- Food and Beverage Industry
- Biochemical Industry
- Oil & Refineries Industry
- Animal Foods and Feeds Industry
- Cosmetics and Personal Care Industry
Advantages and Disadvantages of V Type Blenders
The following are the pros and cons of using V type blenders.
Pros of Using V Type Blenders
- The feeding/charging and discharging of the particles or materials is easy
- They’re easy to clean and operate
- Attrition and particle size reduction are minimized because there are no moving blades
- Little-to-no product contamination
- Can be used for wet mixing as well
These are the pros and advantages of using V type blenders. Now, let’s head on right to the different cons and disadvantages of using V type blenders.
Cons of Using V Type Blenders
- They usually require high headroom because of their movement and locomotive patterns
- V type blenders aren’t the best for blending particles that have different sizes and densities
- Usually more expensive and more costly than other types of blenders and mixers in the market
While you may think of these cons and disadvantages as big factors, they’re not! In fact, you can easily work around these drawbacks!
Parts of a V Type Blender
By knowing and understanding the inner workings of V type blenders, you can easily determine and comprehend the entire process.
Figure 7 – Image that enumerates the different parts and components of a V type blender
So, the following are the parts of V type blenders that you need to know about for you to understand the process more!
Inlet Valve/Feed Inlet
This is the part or the component where you feed the materials to be mixed and blended.
Shell
The shells are the primary component of V type blenders as it’s the location where the procedure of the blending or the mixing will take place.
Support Frame
The support frame is the part or the component that holds the entire machine together. It’s where the machine is attached in order for it to stand.
Chains and/or Chain Drives
The chains or chain drives are the components that control the movement or the rotation of the shells or the chambers.
Discharge Valve/Feed Outlet
And finally, the feed outlet or the discharge valve is the part where the finished products go and come out of the blender or the mixer after the process.
Which V Type Blender Manufacturer Can You Trust?
If you can barely figure out who the best manufacturer of V type blenders to trust, then we here at Yinda Machinery are ready to present to you the library of our V type blenders.
We are skilled and experienced in producing all the different types and kinds of V type blenders that you need for your business!
Yinda Machinery has V type blenders that have 3 to 5 L capacities, while we’re also eligible in producing and providing V type blenders that have 50 to 100 L capacities!
- All our V type blenders are made from high-grade materials
- Before assembly, all parts and components have been checked thoroughly and carefully
- We are employed with the best and the most skilled engineers and experts
- YInda Machinery’s V type blenders have vast range of applications
- We offer free installation and excellent customer service for both pre and aftersales services!
What Can Yinda Machinery Offer?
Other than our V type blenders, you can also bank and count on us if you need other powder handling machines and equipment, such as 3D mixers, vibro sifters, tray dryers, pin mill grinders, and many more!
Should you be in dire need of a V type blender, whether you want to purchase them in retail or in wholesale, Yinda Machinery will never disappoint you!
Contact Us Now For the Best V Type Blenders!
Wherever you are in the world and whatever business you may be in, you can always bank and count on us!
In case you’re not sure about how much budget you will need, don’t fret – we’ll send a free quotation or a free estimate your way!
Reach out to us and never be disappointed with the quality of our products! Contact us via our email or via our hotline and we’ll be more than happy to help and assist!
