Small scale pharmaceuticals grinding machine can grind powder at 20-120mesh. It is widely applied for the pharmaceutical industry, chemical industry, foodstuff industry and etc. Such as herbs& roots, Chinese medicine, agro products, herbal extracts, and relative products all have good grinding efforts. Small scale pharmaceuticals grinding machine makes use of the high-speed relative movement of the movable fluted disc and the fixed fluted disc to crush the material through the comprehensive effect of striking and friction of the fluted disc as well as the mutual striking of the material.
- Price Term: FOB/CIF/EXW
- Package: Wooden case or according to customer request
- Delivery Time: 25-35 working days
- Transports: LCL/FCL
- Shipment Port: Shanghai Port
- Origin Of Place: Wuxi City
- Warranty: 12 Months
- Introduction
- Specifications
Specifications:
| Model | YDWS-20 | YDWS-30 | YDWS-40 | YDWS-60 | YDWS-80 | YDWS-100 |
| capacity（kg/h) | 20-200 | 30-300 | 40-500 | 200-1200 | 300-1500 | 600-3000 |
| Spindle speed(r/min) | 4500 | 3800 | 3600 | 2600 | 2000 | 1600 |
| input size(mm) | ≤10 | ≤10 | ≤10 | ≤12 | ≤ 15 | ≤ 15 |
| output size(mesh) | 20-120 | 20-120 | 20-120 | 20-120 | 20-120 | 20-120 |
| crushing motor(kw) | 4 | 5.5 | 7.5 | 18.5 | 37 | 45 |
| Cyclone collector motor | 2.2kw | 3kw | 4kw | 11kw | 18.5kw | 22kw |
| overall size of main grinding(mm) | 600×600×1200 | 650×650×1350 | 750×750×1400 | 1000×800×1600 | 1200×1000×1800 | 1500×1300 |
Hot-selling Equipments For Your Powder Processing Task
Small Scale Pharmaceuticals Grinding Machine For Your Powder Handling Task:
Since it features a simple structure, firm and stable operation, and good crushing effect, the comminuted material can be discharged directly from the grinding chamber of the host machine and the desired granule size can be obtained by installing screens with different apertures, and the dust is filtered and recovered by dust collector through a bag. In addition, the inner surface of the enclosure becomes smooth through processing, thus changing the powder residual phenomenon due to the coarse inner surface of the previous models.
Designed according to GMP standard and wholly made of stainless steel, this machine has no flying dust during production and can improve the utilization rate of material and reduce the cost of the enterprise, thus reaching the international advanced level.
Benefits of Small scale pharmaceuticals grinding machine:
● Simple structure in linear type, easy for installation, operation, and clean.
● With water cooling jacket around grind chamber and bearing.
● Yinda small scale pharmaceuticals grinding machine has different kinds of knife to let you choose for different kinds of material.
● Different types of dust collector can be equipped toavoid dust spilling.powder flying during production
● Air cooling devicecan be equippedto keep temperature remains normal, so the material color and nature won’t change.
Details of Small scale pharmaceuticals grinding machine:
It is made up of the main chamber, cyclone discharge, dust collector, blower, and control box.
●Small land area
●Highly discharge
●evenly powder
Grinding Chamber:
●SUS 304 material based on GMP standard
●easy to replace the screen
●easy for daily deep clean
Water Cooling System:
● energy-saving circulating water systems
● Used to cool the high temperature caused by the high-speed rotation of the bearings to extend the life of the machine.
