Pharmaceuticals hammer mill can feed directly with big size materials. This Pharmaceuticals Hammer Mill can grind powder at 20-120mesh.
It widely used in industries such as medicine, food, chemical industry, etc, It can crush spice and oily material, whose oil content is less than 25%, and it is also suitable for Chinese herbs, roots, barks with high fiber content.
The crushing size is controlled by a screen, and continuous production can be achieved under normal temperature. Since it features a simple structure, firm and stable operation, and good crushing effect, the comminuted material can be discharged directly from the grinding chamber of the host machine and the desired granule size can be obtained by installing screens with different apertures, and the dust is filtered and recovered by pulse dust collector through pulse bags.
- Price Term: FOB/CIF/EXW
- Package: Wooden case or according to customer request
- Delivery Time: 25-35 working days
- Transports: LCL/FCL
- Shipment Port: Shanghai Port
- Origin Of Place: Wuxi City
- Warranty: 12 Months
- Introduction
- Specifications
| Model | YDGS-400 | YDGS-600 | YDGS-800 | YDGS-1000 |
| Moto power(kW) | 22 | 37 | 45 | 55 |
| Production capacity(kg/h) | 100-1000 | 300-1500 | 600-2000 | 1000-3000 |
| Spindle speed(r/min) | 4000 | 4000 | 4000 | 4000 |
| Feeding size(mm) | ≤ 20 | ≤20 | ≤ 20 | ≤ 20 |
| Final fineness(mesh) | 20-120mesh | 20-120mesh | 20-120mesh | 20 -120mesh |
| Overall size(L*W*H)mm | 5400*1300*2700 | 6800*1300*2700 | 7800*1800*3200 | 8800*2000*3000 |
Hot-selling Equipments For Your Powder Processing Task
Pharmaceuticals Hammer Mill For Your Powder Handling System
In addition, the inner surface of the enclosure becomes smooth through processing, thus changing the powder residual phenomenon due to the coarse inner surface of the previous models. Pharmaceuticals hammer mill is designed according to GMP standard and wholly made of stainless steel, this machine has no flying dust during production, and can improve the utilization rate of material and reduce the cost of the enterprise, thus reaching the international advanced level.
Benefits of Pharmaceuticals hammer mill:
● Simple structure in linear type, easy for installation, operation, and clean.
● With water cooling jacket around the grinding chamber and bearing.
● Adopting advanced world famous brand motor, electric parts, bearing, and operation parts.
● Pharmaceuticals hammer mill can grind spice and oil material with oil content 10%~20%.
● No dust during production and dust can be collected in dust collecting box.
● Air cooling device can be equipped to keep temperature remains normal, so the material color and nature won’t change.
Details of Pharmaceuticals hammer mill:
It is made up of the main chamber, cyclone discharge, dust collector, blower, and control box.
Cyclone Discharge Valve:
●Cyclone can separate dust from powder(granules).
●The rotary valve makes powder discharge speed even.
●The rotary valve is also made of stainless steel and based on the GMP standard.
●Quick-detachable Construction to Make quick and convenient for clean and installation.
Dust Collector System:
●Dust is collected inside the dust collecting box.
●Inside the box, there are many dust collecting bags, the number of dust boxes is precisely calculated according to the filter area. and the bag frames are also made of stainless steel and can be disassembled easily.
●With pulse-jet cleaning, dust can be filtered and collected very conveniently.
Blade structure:
Eu Brand components guarantee quality performance and minimize broken-down time.
